●Advanced etching technology
Using photo etching technology used in the field of electronic parts manufacturing for semiconductors etc, accurate hole is uniformly opened, so filtration accuracy is maintained.

●The risk of contamination is drastically reduced
There is no breakage of the steel wire due to breakage as compared to the wire mesh strainer, and there are few residues due to clogging.

●Excellent Regenerative cleaning
Because the structure is simple, it is excellent in regeneration cleaning and sanitary properties. It is economical because it can be washed and reused.

●Chemical resistance
Alkaline and acid type chemicals are available.

Filter composition

Media： SUS316L,　End Plate： SCS14

Filtration accuracy (Nominal)

　20#,　40#,　60#,　80#,　100#, 120#, 150#, 200#

Filtration area　(㎡)
